Rock wool partition wall panel
PUR / PIR

Corrugated
Roof Panel

Supplier source name: PUR/PIR corrugated roof panel

PUR/PIR corrugated roof panel configuration documented by the supplier. The source information currently available identifies the panel thickness range together with PUR and PIR flammability classes and core densities. Unsupported specifications are intentionally omitted.

Panel Thickness50–100 mm
PURB2/B3 · 38–45kg/m³
PIRB1/B2 · 38–55kg/m³
SourcePUR/PIR corrugated roof panel
Request Project Pricing ↗ Back to IMP Range ←

Thickness Options

Documented panel thicknesses.

The supplier sheet lists the following nominal panel thickness options for this rock wool partition wall panel.

0150 mm
0260 mm
0375 mm
0480 mm
05100 mm

Technical Specifications

Supplier reference data.

This page only shows values supported by the supplier information currently available for Product 09. Steel thickness, thermal conductivity, surface forms, colors and other values are not shown because they are not documented in the source provided.
Supplier source namePUR/PIR corrugated roof panel
Panel thickness50 / 60 / 75 / 80 / 100 mm
PUR flammability classB2/B3
Density of PUR38–45kg/m³
PIR flammability classB1/B2
Density of PIR38–55kg/m³
Rock wool partition wall panel joint detail

Panel Joint

Supplier joint reference.

Use the supplier joint drawing as the controlling reference for the panel-edge geometry. The website product image is a presentation image and should not replace the technical joint detail.

The available product reference includes a circular roof-joint illustration. Keep this image as the visual joint reference; no additional joint dimensions are stated in the source provided.

Need pricing for a PUR/PIR corrugated roof panel project?

Send Atlas the project drawings, panel takeoff or project requirements for material review and project-based pricing.
